JWY无约束型波纹补偿器
设计温度：480℃-750℃产品代号：JWY型号标注；JWY波纹管形式连接形式压力-通径-补偿量
|
通径 DN
|
波数
|
压力等级 MPa
|
波纹管有效面积 cm2
|
量大外径尺寸 mm
|
法兰 JDZ/F (mm)
|
总长 L (mm)
|
|
0.25
|
0.6
|
1
|
1.6
|
2.5
|
|
50
|
8
|
14/153
|
12/318
|
12/318
|
12/635
|
11/1310
|
37
|
120
|
￠57×3.5
|
361
|
|
16
|
27/76
|
24/158
|
24/158
|
24/318
|
23/655
|
445
|
|
32
|
52/38
|
48/79
|
48/79
|
48/159
|
46/328
|
621
|
|
65
|
8
|
19/213
|
18/213
|
18/213
|
18/424
|
15/841
|
55
|
159
|
￠73×4
|
377
|
|
12
|
30/142
|
29/142
|
27/142
|
27/283
|
25/421
|
425
|
|
24
|
60/71
|
58/107
|
54/107
|
54/142
|
50/211
|
581
|
|
80
|
8
|
30/179
|
30/179
|
30/358
|
29/358
|
27/650
|
81
|
162
|
￠89×4
|
430
|
|
10
|
54/143
|
37/143
|
37/286
|
37/286
|
32/325
|
466
|
|
20
|
108/72
|
74/72
|
74/143
|
74/143
|
64/163
|
660
|
|
100
|
6
|
34/138
|
34/277
|
33/417
|
33/417
|
32/817
|
121
|
180
|
￠108×4
|
410
|
|
10
|
56/83
|
56/166
|
56/250
|
54/250
|
50/409
|
492
|
|
20
|
112/42
|
112/83
|
112/125
|
108/125
|
100/205
|
712
|
|
125
|
5
|
37/136
|
36/272
|
36/408
|
35/408
|
33/801
|
180
|
221
|
￠133×4
|
410
|
|
9
|
66/76
|
65/151
|
65/227
|
63/227
|
60/401
|
412
|
|
18
|
132/38
|
130/76
|
130/114
|
126/14
|
120/201
|
711
|
|
150
|
5
|
49/100
|
49/200
|
48/300
|
45/456
|
44/845
|
257
|
245
|
￠159×4.5
|
433
|
|
8
|
88/63
|
78/125
|
77/188
|
71/286
|
65/423
|
518
|
|
16
|
159/32
|
156/63
|
154/94
|
149/143
|
130/211
|
756
|
|
200
|
4
|
58/95
|
56/193
|
56/288
|
56/480
|
55/800
|
479
|
327
|
￠219×6
|
475
|
|
6
|
86/63
|
85/128
|
85/192
|
84/320
|
80/972
|
553
|
|
12
|
172/32
|
170/64
|
170/96
|
168/160
|
160/200
|
800
|
